RJ45 surge protection din rali mounted

Network surge protection device RJ 45

Max. data rate:100Mps

Din rail mounted

OEM/ODM SPD manufacturer


  • Item NO.:

    JLSP-DAE
  • Product Detail

Telecom Network 100M RJ45 Surge Protection Device, ri45 surge protector

Network signal surge protector is widely used in the comprehensive network wiring of office and industrial places and similar data communication systems, such as various computer network equipment, switches, routers, hub, program-controlled switches, small switchboard, telephone, fax machine and other sensitive communication network lines and audio signal lines.

Standard compliance: IEC61643-21

It is designed according to the surge protector standard of IEC communication products. The product has good frequency transmission characteristics, high throughput and extremely fast response, and can protect 2 to 8 communication lines.

Features:

* Low insertion loss and low voltage protection level

* Fast response: action within nanosecond

* High rate transmission

* RJ45 connection

Model Nominal voltage Un(V) Max.continuous operatingvoltage Uc(Vdc) Nominal discharge current In(kA) Protection level Up(line-line)(V)(B2:4kV) Protection level Up(line-PE)(V)(B2:4kV)
Max. data rate (Mbps) Insertion loss(dB)
JLSP-DAE 5 8 5 ≦30
≦600
100 ≦0.3
JLSP-DAP110 110 170 5 ≦300
≦600
100 ≦0.3
JLSP-DAEK 5 8 5 ≦30
≦600
1000 ≦0.3
JLSP-DAS 5 8 5 ≦30 ≦600
1000 ≦0.3
poe surge protector

poe surge protectorpoe surge protector


Keywords: spd rj45, rj45 surge protector, poe spd, rj45 spd, network surge protector, surge protector data line, ethernet surge protector, surge protection rj45
