3 phase 120 208v surge protector

AC SPD 275V,  double pole surge protection device, 2p spd

Uc=275V, In:20kA, Imax: 40kA

Low voltage Up

Internal disconnection, statue indicator, and remote signaling

IEC 61643-11

OEM/ODM SPD manufacturer

SUngrow, Goodwe, Growatt supplier, work with Huawei

  • Item NO.:

    JLSP-GA275/40/2P
  • Product Detail

Jinli single phase AC surge protection device 275V

AC power surge protective device is used in AC power supply system (50/60Hz) and low-voltage control system to protect from lightning striker and transient over-voltage. The maximum operating voltage (Uc): 175V, 275V, 350V, 385V, 440V, 485V and 750V.


Standard compliance: IEC61643-11, EN61643-11

IEC 61643-11 Surge protective devices connected to low-voltage power distribution systems -Part 11: Performance requirements and testing methods


Features:

* Reliable thermal tripping protection

* Status indicator: Green(normal) Red(Defect)

* Fast response: action within nanosecond

* Optional remote signaling

* Pluggable design, easy to mount

* Latest reflow soldering process, ensure product consistency

Model JLSP-GA275/40/2P
Descrpition Type 2 AC surge protector-2poles
Network 202,230,120/208V (TN/TT/IT)
Max. AC operating voltage (Uc) 275V
Nominal discharge current In(kA) 20kA
Max. Discharge current Imax (kA) 40kA
Protection level Up (kV) ≦1.4kV
Dimensions 36*90*62MM
Protection rating IP 20
Response time tA (ns) ≦25
Oeprating temperature  -40/+85℃
Mounting  DIN Rail 35mm
Housing material Thermoplastic UL94-V0
Standards compliance IEC64643-11, GB/T18802.11
surge protective devicessurge protective devicessurge protective devices



Hot tags: ethernet network surge protector, we have 100M and 1000M, can make din rail mounted or normal one, with rj45 port, ect.
